GM37-3530 37mm 12V electric dc gear motor

FOB Reference Price:Get Latest Price
US $4.98-6.98 / Piece | 100 Piece/Pieces gear motor (Min. Order)
Supply Ability:
100000 Piece/Pieces per Month gear motor
Port:
HK
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
TT MOTOR
Model Number:
gear motor TRK-3530-1240
Usage:
Boat, Home Appliance, Medical Instrument
Certification:
CE, ROHS, ISO9001
Type:
Gear Motor
Torque:
0.6-30kg.cm
Construction:
Permanent Magnet
Commutation:
Brushless
Protect Feature:
Explosion-proof
Speed(RPM):
3300-5300r/min
Continuous Current(A):
1.0-1.3A
Output Power:
1.4-3.1w
Voltage(V):
12V, 24V
Efficiency:
65%
Size:
24mm
Product Name:
gear motor TRK-3530-1240
No-load speed:
4000-6000 r/min
No-load current:
30-45mA
Rated torque:
3500-7200g.cm
Output power:
1.4-3.1w
Stall torque:
220-400g.cm
Stall current:
1.0-1.3A
Rated voltage:
12VDC-24VDC
Application:
Automatic Product
Packaging & Delivery
Packaging Details
gear motor: 100 pieces per box
Delivery Time
30 days
Product Description

GM37-3530 37mm 12V electric dc gear motor


Main Features

37mm Eccentric out shaft gearbox plus 520 & 3530 & 3527 and TEC3650 &3640 brushless motor
Small size dc gear motor with low speed and big torque
37mm gear motor provide 1.0Nm torque and more reliable
Suitable to small diameter, low noise and big torque application
SC Gear motors can match encoder, 11ppr
Reduction ratio:6、11、19、30、44、56、90、131、169、270、506、810

Model:motor TRK-3530-1240


TRK-3530-1240
Rated voltage:12V DC
Rated speed:3300r/min
Output power:1.4W
No-load speed:4000r/min
Rated torque:40g.cm
Stall torque:220g/cm
No-load current:35mA
Rated current:180mA
Stall current:1.0A


RK-3530-1250
Rated voltage:12V DC
Rated speed:4200r/min
Output power:1.8W
No-load speed:5000r/min
Rated torque:40g.cm
Stall torque:250g/cm
No-load current:45mA
Rated current:250mA
Stall current:1.2A

TRK-3530-2456
Rated voltage:24V DC
Rated speed:5300r/min
Output power:3.1W
No-load speed:6000r/min
Rated torque:50g.cm
Stall torque:400g/cm
No-load current:30mA
Rated current:180mA
Stall current:1.3A
GM37-3530-1240-xxx
Reduction ratio
6
10
30
44
56
90
169
270
506
Length mm
19
19
21.5
24
24
24
26.5
26.5
29
No-load speed rpm
600
360
120
85
65
45
24
15
8
Rated speed rpm
550
330
110
75
59
36
19
12
6
Rated torque kg.cm
0.2
0.3
0.8
1.1
1.3
2.2
3.7
5.4
10
Max.momentary tolerance torque kg.cm
1.1
1.8
4.6
5.8
7.4
10
15
15
15
GM37-3530-1250-xxx
Reduction ratio
6
10
30
44
56
90
169
270
506
Length mm
19
19
21.5
24
24
24
26.5
26.5
29
No-load speed rpm
800
490
165
110
88
55
30
18
10
Rated speed rpm
670
420
140
95
75
46
25
16
8
Rated torque kg.cm
0.2
0.3
0.8
1.1
1.3
2.2
3.7
5.4
10
Max.momentary tolerance torque kg.cm
1.1
1.8
4.6
5.8
7.4
10
15
15
15
GM37-3530-2456-xxx
Reduction ratio
6
10
30
44
56
90
169
270
506
Length mm
19
19
21.5
24
24
24
26.5
26.5
29
No-load speed rpm
870
540
180
120
95
60
32
20
11
Rated speed rpm
780
485
160
110
87
59
29
18
10
Rated torque kg.cm
0.24
0.3
0.8
1.1
1.3
2.7
4.7
6.7
10
Max.momentary tolerance torque kg.cm
1.9
3.2
8.4
10.6
13.4
15
15
15
15

Product Application

Automatic door operators, automatic energy saving bath,electrical controlled valve,oxygen machine,optical equipment, Automat cordless power tool,lighting,etc.
