Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: TT MOTOR
  • Model Number: electric dc motor GMP36-555PM-EN
  • Usage: Boat, Industrial equipment
  • Certification: CE, ROHS, ISO9001
  • Type: Gear Motor
  • Torque: 30kg.cm max
  • Construction: Permanent Magnet
  • Commutation: Brushless
  • Protect Feature: Other
  • Speed(RPM): 4-1300rpm
  • Continuous Current(A): 0.7-2.4A
  • Output Power: 5.7-16w
  • Voltage(V): 12v 24v
  • Efficiency: 65%
  • Size: 36*93mm
  • Product Name: dc planetary gear motor GMP36-555PM-EN
  • No-load speed: 6-1400 r/min
  • No-load current: 150mA-300mA
  • Rated torque: 0.64-30kg.cm
  • Output power: 5.7-16W
  • Stall torque: 1000g.cm-2200g.cm
  • Stall current: 2.7A-15.0A
  • Rated voltage: 12VDC-24VDC
  • Application: Automatic Product

Packaging & Delivery

Packaging Details DC 24V brushless motor :100 pieces per box
Delivery Time 15-30 days
Product Description

GMP36-555PM-EN 12v dc motor encoder with gear reduction




Product Application

Automatic door operators, automatic energy saving bath,electrical controlled valve,oxygen machine,optical equipment, Automat cordless power tool,lighting,etc.

Model:Gear Motor GMP36-555PM


TTRS-555PM-1233
Rated voltage: 12VDC
Rated speed:2800r/min
Output power:5.7W
No-load speed:3300r/min
Rated torque:200g.cm
Stall torque:1150g.cm
No-load current:200mA
Rated current:1000mA
Stall current:5.5A


TTRS-555PM-1260
Rated voltage: 12VDC
Rated speed:5250r/min
Output power:16W
No-load speed:6000r/min
Rated torque:290g.cm
Stall torque:2200g.cm
No-load current:300mA
Rated current:2400mA
Stall current:15.0A


TTRS-555PM-2440
Rated voltage: 24VDC
Rated speed:3150r/min
Output power:6.4W
No-load speed:2400r/min
Rated torque:200g.cm
Stall torque:1000g.cm
No-load current:150mA
Rated current:700mA
Stall current:2.7A

Main Features

36mm Planetary reducer plus 3530,5 series of carbon brush motor and TEC3650&3640 brushless motor
Small size dc gear motor with low speed and big torque
36mm gear motor provide 3.0Nm torque and more reliable
Suitable to small diameter, low noise and big torque application
Dc Gear motors can match encoder,11pr
Reduction ratio:4、14、19、51、71、100、139、189、264、369、516、720

Related Products
GMP36-555PM-1233-xxx
Reduction ratio
4
19
51
100
139
189
264
369
516
Length mm
26
33.5
33.5
40.5
40.5
47.5
47.5
47.5
47.5
No-load speed rpm
750
160
60
32
23
17
12
9
6
Rated speed rpm
700
150
55
28
20
15
11
8
5.5
Rated torque kg.cm
0.64
2.7
6
12
15
21
26
30
30
Max.momentary tolerance torque kg.cm
3.7
15
35
70
70
70
70
70
70
GMP36-555PM-1260-xxx
Reduction ratio
4
19
51
100
139
189
264
369
516
Length mm
26
33.5
33.5
40.5
40.5
47.5
47.5
47.5
47.5
No-load speed rpm
1400
300
110
55
42
32
23
16
11.5
Rated speed rpm
1300
275
100
50
38
28
20
15
10.5
Rated torque kg.cm
0.9
3.8
9
18
22
30
30
30
30
Max.momentary tolerance torque kg.cm
5
20
60
60
60
70
70
70
70
GMP36-555PM-2440-xxx
Reduction ratio
4
19
51
100
139
189
264
369
516
Length mm
26
33.5
33.5
40.5
40.5
47.5
47.5
47.5
47.5
No-load speed rpm
980
200
75
38
28
21
15
10
7.5
Rated speed rpm
750
155
60
30
21
16
13
9.5
7
Rated torque kg.cm
0.64
2.7
6
12
15
21
26
30
30
Max.momentary tolerance torque kg.cm
3.2
13
25
50
60
70
70
70
70
Packing & Delivery

Packaging: single carton packing, 500 pieces per box.

Shipping time:
DHL: 3-5 working days ;

UPS: 5-7 working days;

TNT: 5-7 working days;

FedEx: 7-9 working days;

EMS: 12-15 working days;

China Post: Depends on ship to which country;

Sea: Depends on ship to which country
