GMP22-180SH 22mm mini planetary gear dc motor 12v

FOB Reference Price:Get Latest Price
US $12.98-19.98 / Pieces | 100 Piece/Pieces 12v planetary geared gmp22 tt motor for home ventilation equipme (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
TT MOTOR
Model Number:
12v planetary geared motor GMP22-180SH
Usage:
Boat, Industrial equipment
Certification:
CE, ROHS, ISO9001
Type:
Gear Motor
Torque:
0.06-0.155kg.cm
Construction:
Permanent Magnet
Commutation:
Brush
Protect Feature:
Other
Speed(RPM):
3.3-520rpm
Continuous Current(A):
0.09-0.45A
Output Power:
0.5-1.8w
Voltage(V):
6v 12v 24V
Efficiency:
65%
Size:
22*64.1mm
Product Name:
12v planetary geared motor GMP22-180SH
Gear Type:
spur teeth
Output Shaft:
Stainless steel hardened
Main Gear:
Alloy steel
Adapter plate:
Aluminium alloy
Bearing At Output:
Ball bearing
Axial Play:
6-12mm
Directions:
CW/CCW
Backlash:
<3°
SupplyAbility
SupplyAbility:
100000 Piece/Pieces per Month 12v planetary geared gmp22 tt motor for home ventilation equipme
Packaging & Delivery
Packaging Details
DC Gear Motor:100 pieces per box
12v planetary geared gmp22 tt motor for home ventilation equipments
Port
SHENZHENG
Lead Time :
15-30 days
Product Description

GMP22-180SH 22mm mini planetary gear dc motor 12v


Main Features

22mm planetary gearbox plus 180&130 permanent magnet DC motor
Small size dc gear motor with low speed and big torque
22mm gear motor provide 0.3Nm torque and more reliable
Suitable to small diameter, low noise and big torque application
SC Gear motors can match encoder, 3ppr
Reduction ratio:16、62、84、104、231、316、370、455、1014

Model:Gear Motor GMP22-180SH


TFF-180SH-09450
Rated voltage: 12VDC
Rated speed:3500r/min
Output power:0.5W
No-load speed:4400r/min
Rated torque:13g.cm
Stall torque:60g.cm
No-load current:25mA
Rated current:90mA
Stall current:0.35A


TFF-180SH-18140
Rated voltage: 6VDC
Rated speed:5300r/min
Output power:1.1W
No-load speed:7000r/min
Rated torque:20g.cm
Stall torque:85g.cm
No-load current:90mA
Rated current:450mA
Stall current:1.90A


TFF-180SH-10400
Rated voltage: 24VDC
Rated speed:8700r/min
Output power:1.8W
No-load speed:10200r/min
Rated torque:20g.cm
Stall torque:155g.cm
No-load current:30mA
Rated current:140mA
Stall current:0.85A
GMP22-180SH-09450-xx
Reduction ratio
16
62
84
104
231
316
370
4555
1014
Length mm
18.1
21.7
21.7
21.7
25.4
25.4
25.4
25.4
29
No-load speed rpm
250
70
50
42
19
13.5
11.5
9.5
4
Rated speed rpm
215
55
40
33
15
11
9
7.5
3.3
Rated torque kg.cm
0.12
0.5
0.6
0.8
1.8
2.4
2.8
3
3
Max.momentary tolerance torque kg.cm
0.5
1.5
2.5
3.5
7
9
9
9
9
GMP22-180SH-18140-xx
Reduction ratio
16
62
84
104
231
316
370
4555
1014
Length mm
18.1
21.7
21.7
21.7
25.4
25.4
25.4
25.4
29
No-load speed rpm
420
110
82
65
30
22
18.5
15
6.5
Rated speed rpm
320
85
62
50
22
17
15
13
5.5
Rated torque kg.cm
0.2
0.7
1.0
1.2
2.5
3
3
3
3
Max.momentary tolerance torque kg.cm
0.5
1.5
3
5
7
9
9
9
9
GMP22-180SH-10400-xx
Reduction ratio
16
62
84
104
231
316
370
4555
1014
Length mm
18.1
21.7
21.7
21.7
25.4
25.4
25.4
25.4
29
No-load speed rpm
600
160
120
95
42
32
26
22
10
Rated speed rpm
520
140
100
80
37
27
24
20
9
Rated torque kg.cm
0.2
0.7
1.0
1.2
2.5
3
3
3
3
Max.momentary tolerance torque kg.cm
1.7
5.8
7.8
8.8
9
9
9
9
9

Product Application

Automatic door operators, automatic energy saving bath,electrical controlled valve,oxygen machine,optical equipment, Automat cordless power tool,lighting,etc.
